 | Introduced: March 14, 1994 Terminated: January 3, 1995 |
Logic Board
Processor: 601
Processor Speed: 60 MHz
2nd Processor: opt. Intel 486DX2-66
PMMU: Integrated
FPU: Integrated
Bus Speed: 30 MHz
Data Path: 64-bit
ROM Size: 4 MB
Level 1 Cache: 32K
Level 2 Cache: optional
Expansion Slots: one 7″ NuBus or PDS
Battery: 3.6V Lithium
Memory
RAM Type: 72-pin SIMM
RAM Slots: 2
Min – Max RAM: 8 MB – 72 MB
Minimum RAM Speed: 80 ns
Install in groups of: 2
RAM Sizes: 4, 8, 16, 32 MB
Onboard RAM: 8 MB
Ports
ADB: 1
USB: none
FireWire: none
Video: HDI-45
Floppy: none
SCSI: DB-25
Geoports: 2
Ethernet: AAUI-15
Mic Type: PlainTalk
Other ports:v Printer, modem, speaker
Video
Standard: 640K HDI-45 DRAM (System RAM)
Maximum: 640K HDI-45 DRAM (System RAM)
Display Resolution:
- 512 x 384, 16-bit
- 640 x 480, 16-bit
- 832 x 624, 8-bit
Note:
- 640K of the system RAM is dedicated to the video function.
Storage
Standard CD-ROM: 2x
Internal Hard Drive: SCSI (160 – 250 MB)
Floppy Disk Drive: 1.44 MB manual
Operating System
Addressing Modes: 32-bit
Original OS: 7.1.2
Original Enabler: PowerPC Enabler v1.0
AppleTalk Version: 58.0.2
Compatible MacOS:
7.1.2
7.5
7.5.1
7.5.3
7.5.5
7.6
7.6.1
8.0
8.1
8.5
8.6
9
Miscellaneous
Codename: Piltdown Man
Form Factor: Centris 610
Dimensions (Inches): 3.4 H x 16.3 W x 15.6 D
Average Weight (lbs): 14
Gestalt ID: 75
Original Price: $1820, $2000, $2350 US
