Introduced: April 15, 1996Terminated: December 1, 1996 Logic BoardProcessor:   603eProcessor Speed:   100 MHzPMMU:   IntegratedFPU:   IntegratedBus Speed:   40 MHzData Path:   64-bitROM Size:   4 MBLevel 1 Cache:   32KLevel 2 Cache:   256KExpansion Slots:   LC, comm, TV, video in/outBattery:   4.5V Alkaline MemoryRAM Type:   72-pin SIMMRAM Slots:   2Min – Max RAM:   16 MB – 64 MBMinimum RAM Speed:   80 nsInstall in groups of:   1RAM Sizes:   4, 8, 16, 32 MBOnboard RAM:   none PortsADB:   1USB:   noneFireWire:   noneVideo:   opt. DB-15Floppy:   noneSCSI:   DB-25Geoports:   noneEthernet:   noneMic Type:   PlainTalkOther ports:   Printer, modem, speaker, … Read more

Introduced: February 2, 1994Terminated: April 3, 1995 Logic BoardProcessor:   68LC040Processor Speed:   33 MHzProcessor Upgrade:   66 MHz with PPC 601, 66 MHz Upgrade CardPMMU:   IntegratedFPU:   None – available via a 68040 upgradeBus Speed:   33 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   8KLevel 2 Cache:   noneExpansion Slots:   LC PDS (filled if using PPC 601, 66 MHz Upgrade Card), CommBattery:   4.5V Alkaline Note: MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max … Read more

Introduced: June 1980Terminated: April 1984 Logic BoardProcessor: Processor Speed:   2 MHz peak, 1.4 MHz averagePMMU:   noneFPU:   noneBus Speed:   2 MHzData Path:   8-bitROM Size:   4K Note: Level 1 Cache:   noneLevel 2 Cache:   noneExpansion Slots:   4 x 50-Pin Proprietary (compatible with Apple II) MemoryMin – Max RAM:   128K – 256KOnboard RAM:   128K – 256K (III Plus) PortsI/O Ports: VideoFour Graphics Modes: Three Text Modes: StorageInternal: External: Operating SystemAddressing … Read more

Introduced: January 1983Terminated: January 1985 Logic BoardProcessor:   68000Processor Speed:   5 MHzPMMU:   noneFPU:   noneBus Speed:   5 MHzData Path:   16-bitROM Size:   16KLevel 1 Cache:   noneLevel 2 Cache:   noneExpansion Slots:   3 Proprietary Lisa SlotsBattery:   Onboard MemoryRAM Type:   Lisa CardsRAM Slots:   2Min – Max RAM:   0.5 MB – 2 MBInstall in groups of:   1RAM Sizes:   512KOnboard RAM:   none PortsADB:   noneUSB:   noneFireWire:   noneVideo:   RCAFloppy:   noneSCSI:   noneGeoports:   noneEthernet:   noneMic Type:   noneOther ports:   Parallel printer port, 2 x DB-9 serial ports, audio out (CVSD), DB-9 mouse port VideoStandard VRAM:   noneMaximum … Read more

Introduced: November 3, 1994Terminated: March 2, 1996 Logic BoardProcessor:   68LC040Processor Speed:   33 MHz Processor Upgrade:   66 MHz with PPC 601, 66 MHz Upgrade CardPMMU:   IntegratedFPU:   Integrated – available via a 68040 upgradeBus Speed:   33 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   8KLevel 2 Cache:   noneExpansion Slots:   PDS, Comm, Video in, TVBattery:   4.5V Alkaline Note: MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max RAM:   4 MB – 36 MBMinimum RAM … Read more

Introduced: October 25, 1993Terminated: February 1, 1995 Logic BoardProcessor:   68030Processor Speed:   32 MHzPMMU:   IntegratedFPU:   noneBus Speed:   16 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   0.5KLevel 2 Cache:   noneExpansion Slots:   noneBattery:   3.6V Lithium MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max RAM:   4 MB – 8 MBMinimum RAM Speed:   80 nsInstall in groups of:   1RAM Sizes:   1, 4 MBOnboard RAM:   4 MB PortsADB:   2USB:   noneFireWire:   noneVideo:   noneFloppy:   noneSCSI:   DB-25Geoports:   noneEthernet:   noneMic Type:   noneOther ports:   Printer, modem, speaker, headphone, remote control VideoStandard VRAM:   512K (Built-in)Maximum … Read more

Introduced: April 3, 1995Terminated: March 2, 1996 Logic BoardProcessor:   68LC040Processor Speed:   33 MHzProcessor Upgrade:   66 MHz with PPC 601, 66 MHz Upgrade CardPMMU:   IntegratedFPU:   None – available via a 68040 upgradeBus Speed:   33 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   8KLevel 2 Cache:   noneExpansion Slots:   LC PDS (filled if using PPC 601, 66 MHz Upgrade Card), Comm, Video in/outBattery:   4.5V Alkaline Note: MemoryRAM Type:   72-pin SIMMRAM Slots:   2Min … Read more

Introduced: February 2, 1994Terminated: March 23, 1995 Logic BoardProcessor:   68030Processor Speed:   33 MHzPMMU:   IntegratedFPU:   opt. 68882Bus Speed:   33 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   0.5KLevel 2 Cache:   noneExpansion Slots:   1 LC PDSBattery:   3.6V Lithium MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max RAM:   4 MB – 36 MBMinimum RAM Speed:   80 nsInstall in groups of:   1RAM Sizes:   1, 2, 4, 8, 16, 32 MBOnboard RAM:   4 MB PortsADB:   2USB:   noneFireWire:   noneVideo:   noneFloppy:   noneSCSI:   DB-25Geoports:   noneEthernet:   noneMic Type:   PlainTalkOther ports:   Printer, modem, … Read more

Introduced: June 28, 1993Terminated: February 2, 1994 Logic BoardProcessor:   68030Processor Speed:   25 MHzPMMU:   IntegratedFPU:   opt. 68882Bus Speed:   25 MHzData Path:   32-bitROM Size:   1 MBLevel 1 Cache:   0.5KLevel 2 Cache:   noneExpansion Slots:   1 LC PDSBattery:   3.6V Lithium MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max RAM:   4 MB – 36 MBMinimum RAM Speed:   80 nsInstall in groups of:   1RAM Sizes:   1, 2, 4, 8, 16, 32 MBOnboard RAM:   4 MB PortsADB:   2USB:   noneFireWire:   noneVideo:   noneFloppy:   noneSCSI:   DB-25Geoports:   noneEthernet:   noneMic Type:   PlainTalkOther ports:   Printer, modem, … Read more

Introduced: October 21, 1993Terminated: July 15, 1996 Logic BoardProcessor:   68LC040Processor Speed:   25 MHz PMMU:   IntegratedFPU:   Integrated – only available via a 68040 upgradeBus Speed:   25 MHzData Path:   32-bitROM Size:   512K (Expandable to 1 MB)Level 1 Cache:   8KLevel 2 Cache:   noneExpansion Slots:   1 LC III PDSBattery:   3.6V Lithium MemoryRAM Type:   72-pin SIMMRAM Slots:   1Min – Max RAM:   4 MB – 36 MBMinimum RAM Speed:   80 nsInstall in groups of:   1RAM Sizes:   1, 2, … Read more
