 | Introduced: July 1, 1994 Terminated: July 1, 1995 |
Logic Board
Processor: 68LC040
Processor Speed: 33 MHz
Note:
PMMU: Integrated
FPU: none
Bus Speed: 33 MHz
Data Path: 32-bit
ROM Size: 1 MB
Level 1 Cache: 8K
Level 2 Cache: none
Expansion Slots: LC, comm, TV, video in
Battery: 4.5V Alkaline
Memory
RAM Type: 72-pin SIMM
RAM Slots: 1
Min – Max RAM: 4 MB – 36 MB
Minimum RAM Speed: 80 ns
Install in groups of: 1
RAM Sizes: 1, 2, 4, 8, 16, 32 MB
Onboard RAM: 4 MB
Ports
ADB: 1
USB: none
FireWire: none
Video: DB-15
Floppy: none
SCSI: DB-25
Geoports: none
Ethernet: none
Mic Type: PlainTalk
Other ports: Printer, modem, speaker, headphone, remote control
Video
Standard DRAM: 1 MB (Built-in)
Maximum DRAM: 1 MB (Built-in)
Display Resolution:
- 512 x 384, 16-bit
- 640 x 480, 16-bit
- 800 x 600, 8-bit
- 832 x 624, 8-bit
- Video in not supported at 832 x 624
Storage
Standard CD-ROM: none
Internal Hard Drive: IDE (250 MB)
Floppy Disk Drive: 1.44 MB manual
Operating System
Addressing Modes: 24-bit or 32-bit
Original OS: 7.1.2P
Original Enabler: System Enabler 405
AppleTalk Version: 57.0.4
Compatible MacOS:
7.1.2P
7.5
7.5.1
7.5.3
7.5.5
7.6
7.6.1
8.0
8.1
Miscellaneous
Macintosh Counterpart: Quadra 630
Form Factor: Quadra 630
Dimensions (Inches): 4.3 H x 12.6 W x 16.5 D
Average Weight (lbs): 19
Gestalt ID: 98
Original Price: $1500 US
Comments
The Performa 630 had 4 MB or 8 MB of RAM, and a 250 MB hard drive. The Performa 630CD shipped with a 2X CD-ROM drive.
